Solar Panel Cleaning Robot

Your Professional Solar Panel Cleaning Robot Supplier



Our goal is to be your true partner in Centralized Solar Panel Cleaning Robot field in China.Shanghai Beffo Technology Co., Ltd, headquartered in Shanghai, is mainly responsible for product marketing and company operation; The R&D base is set up in Changchun, Jilin Province, which is responsible for the R&D, production and after-sales of products. For a long time, Westrong has insisted on honesty, scientific and technological innovation, excellent quality, and high-quality service. The company has always integrated the core concept of "rigorous and pragmatic, technology first, quality first, and everything based on customer needs" into all aspects of product R&D, design, production, sales, and service, so that customers can truly rest assured, worry free, and at ease.




First 123 Last 1/3


Why Choose Us

Our Certificate

Trademark, utility model patent, software copyright, ISO9001 certification

Production Equipment

Machine tool, bending machine, welding machine

Production Market

The products have been exported to Australia, South America, Germany, Italy, South Korea, Singapore, Turkey, Brazil, Taiwan and other regions. Now we have signed contracts with many excellent overseas agents in the industry.

Our Service

Guided by high quality and cost control, Westrong carefully selects suppliers of various parts and automatic systems to 24-hour hotline for enterprises to provide customers with pre-sales, in sales and after-sales services at any time.



Advantages of Solar Panel Cleaning Robot



Enhancing Solar Panel Efficiency

One of the primary benefits of using solar panel cleaning robots is the significant improvement in solar panel efficiency. Dust, bird droppings, and other pollutants can block sunlight and reduce the energy output of solar panels. Robotic cleaners are designed to remove these obstructions efficiently, ensuring that the panels can absorb maximum sunlight and produce optimal energy.

Cost-effective Maintenance

While the initial investment in a solar panel cleaning robot May seem high, it is cost-effective in the long run. Traditional cleaning methods often require hiring professionals, which can be expensive over time. Robots, on the other hand, provide consistent and thorough cleaning with minimal human intervention, reducing labor costs and the need for frequent maintenance services.

Consistent Cleaning Schedules

Solar panel cleaning robots can be programmed to clean at regular intervals, ensuring that the panels are always free from debris. This consistency in maintenance helps prevent the buildup of dirt and grime, which can be difficult to remove if left unattended for long periods. Regular cleaning schedules ensure that the panels are always operating at their best.

Safety And Accessibility

Cleaning solar panels manually can be a risky task, especially for installations on rooftops or in hard-to-reach areas. Solar panel cleaning robots eliminate these safety concerns by automating the cleaning process. They are equipped with advanced navigation systems that allow them to move safely and efficiently across the panels, even in challenging environments.

Eco-friendly Solution

Solar panel cleaning robots are an eco-friendly solution for maintaining solar panels. Traditional cleaning methods often involve the use of water and chemicals, which can have negative environmental impacts. Robotic cleaners, however, use minimal water or no water at all, and are designed to operate without harmful chemicals, making them a sustainable choice for solar panel maintenance.

Prolonged Panel Lifespan

Regular cleaning by robots not only enhances efficiency but also prolongs the lifespan of solar panels. Accumulated dirt and debris can cause wear and tear over time, potentially damaging the panels. By keeping the panels clean, robots help maintain their condition and extend their operational life, providing a better return on investment for solar panel owners.



Applications of Solar Panel Cleaning Robot





BQ-1200 Water Pipe Solar Panel Cleaning Robot
  • Commercial Buildings

    They can be used to maintain solar panels on large rooftops, reducing the need for manual cleaning and improving energy output.

  • Residential Solar Systems

    Robots can help homeowners maintain the efficiency of their rooftop solar panels, ensuring optimal energy production.

  • Agricultural Applications

    They can be used in agricultural areas to clean solar panels used for irrigation, farm power, or other purposes.

  • Industrial Applications

    Robots can clean solar panels used in factories, warehouses, or other industrial facilities.



Product Description

Net weight

Full fuselage

29kg(including rolling brush)

Main machine (excluding roller brush)

≈20KG

Forward rolling brush

≈9KG

Size

Main machine (excluding roller brush)

1300*1320*400mm

Rolling brush

1100mm

Operating Angle

Dry washing

0 °-20 °

Water washing

0 °-15 °

Operating parameter

Battery power

24V 26Ah

Charging time

About 5 -6 hours

Endurance time

About 4-5 hours

Remote control distance

150m

Travel speed

0.18-0.20 m/s

Number of motors

1

Rated motor power

100W

Maximum span gap

5cm

Functional module

Path planning

NO

Lower left start

NO

Lower right start

NO

Start/stop

YES

AI line patrol correction

NO

Forward anti-drop

YES

Side drop

NO

Rear side anti-fall

NO

Air pressure sensor

NO

Odometer

NO

IMU sensor

NO

Working environment

Component height drop

Max. 40mm

Component splicing distance

Max. 50mm

Component surface temperature

Minus 10 to 40 degrees

Wind rating

39~49 km/h strong wind

Class of protection

IP65



Product Specification

Machine size (L * w * h)

1300*1320*400mm

Chassis weight

26kg (excluding battery roller brush)

Roller brush weight

13kg

Scraper weight

2.0kg

Battery weight

7.2kg

Total weight

48.2kg

Roller brush length

1200mm

Squeegee length

1200mm

Lithium Battery Specification

48V 20Ah

Travel speed

50M / min (horizontal panel)

Cleaning efficiency

2000-3000m2/h ①

Roller brush speed

300r/min

Remote control distance

50m

Gradeability

< 20 ︒

Horizontal crossing capacity

400mm

Track width

100mm

Length of equipped water pipe

100m

Ingress protection

IP65

Recommend water flow

14L/min, 12-14Mpa



Delivery

Package Size

90.00cm * 75.00cm * 65.00cm

Package Gross Weight

72.000kg



Lead Time

Quantity (sets)

1 - 1

2 - 15

16 - 100

> 100

Lead time (days)

5

15

30

To be negotiated





Packaging & Shipping



productcate-550-693





FAQ



Q: How to get some samples?

A: We can provide you with samples for quality inspection. Please contact us for more discounts and profitable project solutions.

Q: How do you deliver the goods and how long does it take to arrive?

A: We usually transport by DHL, United Parcel Service, FedEx or TNT. Air and sea transportation are also optional.

Q: Where is your loading port?

A: We have two factories in Xi 'an and Baoji. The loading port can be Tianjin/Shanghai or Shenzhen/Guangzhou.

Q: What is the delivery time of your factory?

A: 2-5 Days in sample orders, 7-10 days in minimum order quantity and 15-30 days in 20-foot container.

Q: Can I print my logo on the product?

A: Yes. Please inform us formally before production, and first confirm the design according to our samples.

Q: Do you guarantee the products?

A: Yes, our products are guaranteed for one year.

We're well-known as one of the leading solar panel cleaning robot manufacturers and suppliers in China. Welcome to buy high quality solar panel cleaning robot for sale here from our factory. Good service and competitive price are available. BR10 PV panel cleaning robot, autonomous pv solar panel cleaner, night vertion solar panel cleaning robot
